Vintage Crown PS-200 Power Amplifier Stereo Pro Studio Audio Amp PS200 Untested



Item: Vintage Crown PS-200 Power Amplifier Stereo Pro Studio Audio Amp PS200 Untested. Power output: 100 watts per channel into 8?

(stereo), 345 watts into 8? Frequency response: 1Hz to 20kHz. Total harmonic distortion: 0.05%.

Signal to noise ratio: 112dB. Dimensions: 483 x 133 x 257mm. The Crown PS-200 power amp is designed. As a lower power companion for the PS. Like the 400 model, the PS-200 is.

Designed, built and available only for profes. The PS-200 features a sophisticated circuit.

That tracks low frequency amplitude to deter. Mine the allowable proportion of sub-audio.

The low frequency interrupt user. Defeatable by internal modification detects. Dangerous levels of sub-audio output.

The PS-200 is another powertul, all-day. Reliable Crown amplifier, unaffected by mis. Matches, shorted outputs or low impedance. The PS-200 is built around the Crown multi.

Mode® circuit design, which provides utmost. Reliability and sonic accuracy at all listening. The multi-mode circuit, a three stage. AB+B design, functions at low levels as a. Levels, the two-stage drivers continue as Class.

A devices with the output stages in Class B. High power levels, the multi-mode circuit drivers. Function in the AB mode, with output stages. Adding more Class B power. Design uses output devices efficiently and.

Powerfully, minimizes amp distortion whether. Audible or test-bench detectable, and provides.

Comparator alerts the user in the unlikely event. That distortion of any kind exceeds 0.05%. Exceptionally Low Distortion: Advanced mu/ti. Mode AB+B design results in exceptionally low. Bridge-Mono Mode: Bridge-Mono mode is.

Provided for double output voltage. Passive Cooling System: Convection cooling with. Massive heatsinks and thermal-coupled chassis.

Note: The following performance measurements. Were made in Stereo mode with both channels. Driven into an 8 ohm load. Frequency Response: +0.1 dB from DC (0 Hz) to.

20 kHz at 1 watt. Phase Response: +0°, -15° from DC (0 Hz) to 20.

Signal to Noise Ratio: 112 dB (20 Hz to 20 kHz). 20 Hz to 400 Hz and increasing linearly to. 0.05% at 20 kHz at 95 W. 10 mW to 0.25 W and. Slew Rate: 12 V per microsecond.

Damping Factor: >400 from DC (0 Hz) to 400 Hz. Note: Maximum average power at 1 kHz with. Stereo: 170 W per channel into 4 ohms. Bridge-Mono: 345 W into 8 ohms.

Load Impedance: Rated for 16, 8, 4 ohm use. Safe with all types of loads, even reactive ones.

Required AC Mains: 50-400 Hz AC with selectable. Transformer taps for 100, 120, 200, 220 and 240. AC Line Connector: Standard three-wire grounded. Power: A pushbutton located on the front panel to. Turn the amplifier on and off. Level: A signal level control for each channel. Located on the front panel. Stereo-Mono: A two-position switch located on. The back panel selects between Stereo and.

Power: An amber indicator which shows the unit. 10C: Normally off, these red indicators flash in the. Rare event the output waveform differs from that. Of the input by 0.05% or more.

Signal Presence: These green indicators flash. Synchronously with the input signal to show its. For each channel and three-terminal barrier.

Accessory Input: Eleven-pin radial socket accepts. Optional active or passive balanced input module. Input Impedance: Nominally 30 K ohms. Input Sensitivity: 1.30 V for rated power into 8. Output Connector: Color coded binding posts.

(banana jacks) and four-terminal barrier block. Chassis Ground: Two-terminal barrier block with. All aluminum construction for maximum heat.

Front panel with splatter coat black chassis and. (48.3 cm) wide, 5.25 in.

Cm tall, 10.1 in. (25.7 cm) deep behind front.

Weight: 25 Ibs (11.3 kg). Mounting: Standard EIA 310 front-panel rack.
