QSC GX5 Professional Power Amplifier 700 Watt 2 Channel (Pro DJ Amp) Rack Mount


The QSC GX5 is a 2-channel power amplifier delivering 500 W per channel at 8 ohms and 700 W per channel at 4 ohms (1 kHz). It features a 2-tier Class H output design, built-in subwoofer crossover, and weighs 28 lb (12.6 kg).

Power Output & Audio Specs. 8 ohms / 1 kHz (both channels driven). 8 ohms / 1 kHz (single channel driven). 4 ohms / 1 kHz (both channels driven).

4 ohms / 1 kHz (single channel driven). 20 Hz-20 kHz (+0, -1 dB).

100 dB (20 Hz-20 kHz). Less than 0.02% (8 ohms), less than 0.05% (4 ohms). XLR, 1/4 TRS balanced, and unbalanced phono jacks. Speakon, 1/4 jacks, and binding posts. Full Range / Crossover switch (100 Hz low-pass for sub, high-pass for top).

Detented gain control knobs (21 detents), Signal and Clip LEDs, Power LED. 3.5" (89 mm) height - 2 rack units (2RU), 19" (483 mm) width, 10.1 (257 mm) depth.

28 lb (12.6 kg). In the QSC GX5 comes down to a design balance between live sound reliability, simple analog circuitry, and cost. While Class D is the modern standard for lightweight gear, QSC chose Class H for this specific line to deliver high performance without the complexity or cost of digital switching. How Class H Works (The GX5 Approach). Class H is an evolution of traditional analog architecture (Class AB).

For normal everyday volumes, it runs on the lower voltage rail to save power and reduce heat. When a massive audio peak hits, it instantly shifts to the high-voltage rail to prevent clipping. You get clean, hard-hitting analog power that runs much cooler than a standard amplifier, but uses a proven transformer design. What's Included: Pictures are of the actual item and included accessories.

This only includes what is pictured and listed above. Utilizing clean, used supplies whenever possible. Feel free to reach out with any/all questions. To avoid any potential issues. We are here to provide customer service and support both before and after the sale. Thanks for viewing our listings.
