Bose Professional FreeSpace IZA 2120-HZ Integrated Zone Amplifier



New Bose FreeSpace IZA 2120-HZ Integrated Zone Amplifier. 2 Channel x 120W Each. For background/foreground music and paging applications, Bose Professional FreeSpace IZA 2120-HZ integrated zone amplifier elevates the audio experience when using FreeSpace loudspeakers. Optimized for commercial applications, FreeSpace IZA amplifiers feature selectable Loudspeaker EQ to enrich audio quality, Opti-Voice paging for clear speech intelligibility while providing seamless transitions and Dynamic EQ that ensures full and balanced music at any volume level. True two-zone capability provides two independent outputs that each support volume/source selection remotes, EQ, tone controls, and paging/auxiliary routing options.

Opti-Voice paging equalizes the vocal frequency range for clear speech intelligibility while providing seamless transitions. Dynamic EQ ensures full and balanced music at any volume level. Independent Loudspeaker EQ per output enriches audio quality and simplifies connection to Bose Professional loudspeakers: FreeSpace 3 systems, FS3 subwoofer, FS2, FS4 and DesignMax DM2.

Dual remotes support optional volume/source selection for independent, or combined, zone control which eliminates the need for bulky, inefficient, and sound-altering 70/100V in-line volume controls. Reliable 2 × 120 W Class-D amplification optimized for 70/100V high-impedance applications. Intuitive feature setup enables the amplifier to be configured without a PC for remote, paging, auxiliary input/output and automatic standby options.

Auto-Standby feature allows the amplifier to consume less power when not in use. Simplified front panel interface provides end users with tone, source selection and master volume controls as well as a connection to mobile sources via a 3.5 mm connector. Remote muting allows the amplifier to be muted via a centralized control system.

Designed for a wide range of applications, including. 58 dBu below rated power, 1 kHz. 55 Hz - 20 kHz (+0 dB/-3 dB) at 1 W, 1 kHz reference. 120 W per channel at 70V, 100V. 0.3% at rated power. 0 dB to -30 dB, line / 0 dB to +50 dB, page / fixed, auxiliary. 2 unbalanced, line + 2 balanced, line + 1 balanced, mic/line (page) + 1 unbalanced, line (auxiliary).

(2) RCA stereo pairs, (2) 5-pin Euroblock, (1) 4-pin Euroblock, (1) 1/8-in (3.5 mm) TRS. 8 dBu to +22 dBu, line / -58 dBu to +12 dBu, page / -60 dBu to -1 dBu, auxiliary. 22 dBu, line / 12 dBu, page / -1 dBu, auxiliary. 4 dBu, line / -38 dBu, page / -8 dBu, auxiliary. 8 dBu, line / -3 dBu, auxiliary / N/A, page.

(2) 2-pin inverted Euroblock, (1) RCA stereo pair. 2 × 120 W at 70V, 100V / 2 dBu (auxiliary). 6.6 A at 120 VAC, 60 Hz / 12.6 A at 230 VAC, 50 Hz. 100-240 VAC (±10%), 50/60 Hz.

High temperature, output short circuit, excessively low/high AC line voltage. 26 W standby, 300 W maximum. (1) power switch, (1) input selection switch, (2) treble knobs, (2) bass knobs, (1) master level knob.

Amplifier Mode DIP switches, Loudspeaker EQ preset selector, Input Gain (A/B/Page), Output trims, Remote (x2). (1) power LED, (1) input signal/clip LED, (1) output signal/clip LED.

10.4 ms (analog input to analog output). High-pass filter, Bose Professional loudspeaker presets (FreeSpace FS2C/FS2P/FS2SE/FS4CE/FS4SE, FreeSpace 3 Acoustimass & DesignMax DM2C-LP/DM2S/DM3C/DM3SE). Loudspeaker EQ, Opti-Voice EQ (paging), Dynamic EQ (low-end compensation). Single fan creates continuous left-to-right air flow. 1.7 in × 19.0 in × 12.8 in (44 mm × 483 mm × 324 mm).

9.0 lb (4.1 kg).
